CULT
DEVOTION 26”
22” TT
100% CROMO Frame
Vintage style loop tail rear end
100% CROMO Fork
Heavens Gate Begin Grips
CULT Forged Salvation V5 Top Load Stem
Integrated Headset
CULT Nylon Pedals
Heat Treated CROMO 3 pc 175mm
Sealed Mid Bottom Bracket
CULT 410 Chain
Sealed Front Female Hub
Sealed 10T Cassette Hub
CULT Match Rims
25T Alloy Member Sprocket
CULT Pivotal Seat
CULT x VANS 26 x 2.10 Tires
990 U-Brake
All Black Everything...
30 lbs...
CONTROL
20.75” TT
100% CROMO Frame
9" CROMO 2-piece Bars
Heaven's Gate Begin Grips
CULT Forged Salvation V5 Top Load Stem
Integrated Headset
CULT Nylon Pedals
Heat Treated CROMO 3 pc 170mm cranks
Sealed Mid Bottom Bracket
CULT 410 Chain
Sealed Front Hub
Sealed 9T Cassette Hub
CULT Match Rims
25T Member style Sprocket
CULT Pivotal Seat
2.40 CULT x VANS Tires
Removable 990 U-Brake [installed]
All Black Everything...
25 lbs...
GATEWAY
20.5” TT
CROMO Front Triangle
9" 2-piece Bars
Heaven's Gate Begin Grips
Top Load Stem
Integrated Headset
CULT Nylon Pedals
Heat Treated CROMO 3pc 170mm cranks
Sealed Mid Bottom Bracket
CULT 410 Chain
Sealed Front Hub
Sealed Rear 9T Cassette Hub
CULT Match Rims
25T Member style Sprocket
1pc Padded Seat w/ CULT logo
2.40 CULT x VANS Tires
990 U-Brake
White Frame / All Black Everything...
25 lbs...
ACCESS
ACCESS
20” TT Frame
9" 2-piece Bars
Heaven's Gate Begin Grips
Top Load Stem
Integrated Headset
CULT Nylon Pedals
3 pc 170mm Cromo Cranks
Sealed Mid Bottom Bracket
CULT 410 Chain
9T Cassette Hub
CULT Match Rims
25T Member style Sprocket
1pc Padded Seat w/ CULT logo
2.40 CULT x VANS Tires
990 U-Brake
Clear Coat Raw Frame / All Black Everything...
26 lbs...
12" CULT
JUVENILE 12”
Lightweight 6061 Aluminum Frame
Upgraded Geometry (13.25” TT)
Short Rear End
Integrated Headset
Mini CULT Dehart Grips
Front Load Stem
CROMO 3 pc 92mm Cranks
Sealed Mid Bottom Bracket
CULT 410 Chain
9T Cassette Hub
25T Member style Sprocket
Padded Seat w/ CULT logo
2.20 CULT x VANS Camo Tires
Caliper Hand Brake
Grey Frame / All Black Everything...
14 lbs...
KINK
The 2022 Curb, which is available in four great colorways, offers the entry-level rider a bike that looks and feels like a pro model without the price tag. Whether you choose Matte Blood Blue, Matte Midnight Black, Gloss Blood Orange, or Matte Brushed Silver, you are getting an amazing bike.
Featuring modern geometry and outfitted with components such as 8.75” Kink T875 bars, 3-piece tubular chromoly cranks, a raised Mission Control TL stem, soft Kink Paragon grips with push-in Kink Thrust bar ends, and 2.4” tires front and rear; the Curb is perfect for any rider looking for a solid first bike.
* Taxes, shipping, destination charge, and/or assembly fees may apply.
GEOMETRY
| Toptube Length |
20" |
| Chainstay Length |
13.25" |
| Headtube Angle |
74.5° |
| Seattube Angle |
71° |
| Standover Height |
8.5" |
| Bottom Bracket Height |
11.6" |
| Fork Offset |
32mm |
The 2022 Launch continues the legacy of a truly remarkable bike. This bike is still one of the best value priced models in the market, hands down, year after year. Available in Gloss Galaxy Green, Matte Storm Grey, and Gloss Iridescent Black colorways, the Launch pairs its great color selection with even better components.
The Launch is equipped with both a sealed integrated headset and sealed Mid bottom bracket, which drastically improves performance and virtually eliminates maintenance of these components. Combined with a parts package that includes Kink Stryker forks, Kink T875 8.75” bars, and Mission Triumph 3pc tubular chromoly cranks, this bike is a rookies dream.
* Taxes, shipping, destination charge, and/or assembly fees may apply.
GEOMETRY
| Toptube Length |
20.25" |
| Chainstay Length |
13.25" |
| Headtube Angle |
75° |
| Seattube Angle |
71° |
| Standover Height |
8.75″ |
| Bottom Bracket Height |
11.6" |
| Fork Offset |
32mm |
TREY JONES SIGNATURE AND SIGNED MATTE RAW COMPLETE
SPECIFICATIONS
- Frame: 100% Chromoly Butted Top Tube & Down Tube
- Top Tube: 21.0″
- Chain Stay: 13.5″
- Head Tube: 75°
- Seat Tube: 71°
- Stand Over: 9.0″
- BB Height: 11.6″
- Brake Mounts: Removable
- Fork: Shadow Inceptiv Forks
- Bars: 100% Chromoly – 2pc 9.0″
- Grips: Subrosa Griffin DCR
- Bar Ends: Shadow Nylon
- Headset: Shadow Stacked
- Stem: Shadow Treymone
- Front Rim: Shadow Truss
- Rear Rim: Shadow Truss
- Front Hub: Shadow Symbol Front
- Rear Hub: Shadow Symbol Cassette
- Tires: Subrosa Sawtooth
- Cranks: Shadow Killer
- Bottom Bracket: Sealed Mid
- Sprocket: Subrosa Petal
- Gearing: 25 – 9
- Chain: Shadow Interlock V2
- Pedals: Shadow Metal Pedal Sealed
- Seat: Shadow Penumbra Jones Series 9
- Seat Clamp: Shadow Alfred
- Brake Lever: Rant Hinged
- Brakes: Rant Spring Brakes V2
- Weight: 12.17 kg = 26.6 lbs
NEXT
SUBROSA
SALVADOR
- Frame: Chromoly Top Tube, Down Tube, & Wishbone
- Top Tube: 20.5″
- Chain Stay: 13.2″
- Head Tube: 75°
- Seat Tube: 71°
- Stand Over: 9.0″
- BB Height: 11.6″
- Brake Mounts: Welded
- Fork: Chromoly Steer Tube – 30mm Offset
- Bars: 100% Chromoly – 2pc 9.0″
- Grips: Shadow Gipsy DCR
- Bar Ends: Shadow Nylon
- Headset: Rant Bang Ur Integrated
- Stem: Rant Trill Top Load
- Front Rim: Rant Squad 36H Alloy Single Wall
- Rear Rim: Rant Squad 36H Alloy Single Wall
- Front Hub: 3/8″ Sealed Alloy
- Rear Hub: Rant Party On V2 Sealed Cassette Male Axle
- Tires: Subrosa Sawtooth 20? x 2.35?
- Cranks: Rant Bangin’ 8 Chromoly 3pc 170mm
- Bottom Bracket: Sealed Mid
- Sprocket: Subrosa Petal Steel
- Gearing: 25 – 9
- Chain: Rant Max 410
- Pedals: Rant Trill Plastic
- Seat: Subrosa Mid 1pc Combo
- Seat Clamp: Shadow Alfred
- Brake Lever: Alloy 2 Finger
- Brakes: Rant Spring Brakes V2
- Weight: 12.54 kg = 27.6 lbs
TIRO XL
- Frame: 100% 1020 Hi-Ten
- Top Tube: 21″
- Chain Stay: 13.2″
- Head Tube: 75°
- Seat Tube: 71°
- Stand Over: 8.5″
- BB Height: 11.6″
- Brake Mounts: Welded
- Fork: Chromoly Steer Tube – 30mm Offset
- Bars: 100% 1020 Hi-Ten – 2pc 9.0″
- Grips: Shadow Maya DCR
- Bar Ends: Shadow Nylon
- Headset: Rant Bang Ur Integrated
- Stem: Rant Trill Top Load
- Front Rim: Rant Squad 36H Alloy Single Wall
- Rear Rim: Rant Squad 36H Alloy Single Wall
- Front Hub: 3/8″ Loose Alloy
- Rear Hub: 14mm Sealed Cassette
- Tires: Rant Squad 20? x 2.35″
- Cranks: Chromoly 8 Spline 3pc 170mm
- Bottom Bracket: Sealed Mid
- Sprocket: Subrosa Petal Steel
- Gearing: 25 – 9
- Chain: Rant Max 410
- Pedals: Rant Trill Plastic
- Seat: Subrosa Mid 1pc Combo
- Seat Clamp: Shadow Alfred
- Brake Lever: Alloy 2 Finger
- Brakes: Rant Spring Brakes V2
- Weight: 12.42 kg = 27.4 lbs
SUBROSA WINGS 18" PARK BIKE PURPLE
PRODUCT SPECS
-
FRAME MATERIAL: 1020 Hi Ten Steel
-
WHEEL SIZE: 18"
-
TOP TUBE LENGTH: 17.5"
-
CHAIN STAY LENGTH: 12.2"
-
HEADTUBE ANGLE: 75°
-
SEAT TUBE ANGLE: 71°
-
FORKS: Chromoly steer tube - 30mm offset
-
BARS: 1020 Hi Ten 2pc - 7.75"
-
STEM: Rant Trill Front Load 48mm
-
HEADSET: Rant Bang Ur Intergrated
-
BRAKE MOUNTS: Welded
-
BRAKES: Rant Spring Brakes V2 with Rant Gravitron Detangler
-
FRONT HUB: 3/8" Loose Alloy
-
FRONT RIM: Rant Squad 36H Alloy Single Wall
-
REAR HUB: 14 mm Sealed Cassette
-
REAR RIM: Rant Squad 36H Alloy Single Wall
-
TYRES: Rant Squad 18x2.30"
-
SPROCKET: Subrosa Petal Steel
-
CRANKS: Chromoly 8 Spline 3pc 155mm
-
BB: Sealed Mid
-
PEDALS: Rant Trill Plastic
-
SEAT: Subrosa Slim 1pc Combo
-
GEARING: 25/9
-
WEIGHT: TBC
PRODUCT HIGHLIGHTS
- 18" Wheels are great for riders just a bit too small to manoeuvre a full size 20" Bike (approx 3ft 4 - 4ft 4 / 100cm-130cm)
- Best suited to skatepark use but can be used on for all types of Riding
- Aftermarket parts from Shadow, Subrosa & Rant
- Strong Hi-Ten steel frame
- Sealed rear cassette
